Camilla – APRS bei GMA
Camilla nennt sich die Server-Software, die innerhalb von GMA für APRS zuständig ist. Die Software läuft seit 2018 und steht seit 2020 ausschließlich registrierten GMA-Usern zur Verfügung.
Camilla ist über das Internet mit einem APRS-IS-Server verbunden. Über die APRS-Station DL0QW-12 können Spots in das GMA-Netz und zu SOTA gesendet sowie verschiedene Informationen abgerufen werden.
Camilla – APRS at GMA
Camilla is the name of the server software responsible for APRS within GMA. The software has been running since 2018 and has been available exclusively to registered GMA users since 2020.
Camilla is connected to an APRS-IS server via the Internet. Using the APRS station DL0QW-12, users can send spots to the GMA network and to SOTA, as well as request various information.
| Description | Command (send message to DL0QW-12) |
|---|---|
| Check connection to DL0QW-12 | hallo or hello or moin or 73 ... or vy ... |
| Send spot |
callsign reference qrg mode [notice] example oz7ccc/p oz/oz-012 7034.5 cw now qrv if your APRS-callsign (minus SSID) is your callsign (plus /P) on the air, you can use a # as your callsign example: on APRS = mw0gqy-7 # gw/nw-070 7034.5 cw now qrv spots MW0GQY/P on GW/NW-070 Separator is always a blank (space) you can spot all references: Islands, Summits, Castles, WWFF, Lighthouses If Camilla identifies the reference as a SOTA summit, she will also place a spot on SOTAwatch2. Spotting station is DL0QW The order of the data is not important; however, the comment must always be made last new The frequency can be given in kHz or MHz, only amateur radio frequencies are covered. You will always get an answer from Camilla if the spot was spotted at GMA or at GMA and SOTA. |
| DX |
DX-Cluster-Spot example: dx dl0gma/p 7035 GMA da/th-001 dlff-0128 This function is only valid for users registered in GMA. |
| new RBN |
Set RBN Monitor example: rbn dl0gma/p DA/TH-001 This function activates a 45 minute RBN monitor on DL0GMA/P. It spots you on GMA and associated spotting tools. QSY or initial spots are then triggered automatically. Another rbn-command overwrites the first (if you change the reference during the monitor period). |
| Distance, antenna direction |
qrb Loc1 Loc2 example: qrb jo42ah jo34we 6-digit Maidenhead-Locator is required returns distance in km, antenna direction and reverse antenna direction |
| Welcome Message |
If the greeting on a Summit annoys you or you think it's spam, you can turn it off welcome off Or turn it back on later. welcome on Camilla will send you a confirmation each time You can now also send an email to nowelcome@gma.rocks and enter your callsign in the subject line. |
| Help | send ? or help |
| Information | send info for GMA information |
| WCY | new send wcy for latest information from DK0WCY |
